Atomos Ninja TX GO

HDMI & CFexpress 5-inch Monitor-Recorder

MPN: 0814164023191 SKU: AOATOMNJTX02

$825.00

Introducing the newest addition to the Ninja line‑up, the Ninja TX GO - an affordable, all‑in‑one monitor‑recorder built for HDMI workflows with DSLRs and mirrorless cameras. With its 5-inch, 1500-nit HDR touchscreen, Ninja TX GO offers a far superior monitoring experience than the camera’s built-in display. It features professional tools such as EL Zone™, waveform, vectorscope, focus peaking, and more, giving content creators complete control over framing, exposure, and colour accuracy on-set.

Seen it cheaper?

Ask our team about our Price Match Pledge.

Get in touch

In stock

Usually Ships in 1-2 Days

A new HDMI monitor-recorder that brings the performance of the acclaimed Ninja TX to an even wider community of filmmakers and creators. Built for HDMI-based cameras, Ninja TX GO combines a brighter screen, advanced monitoring tools, professional codecs, camera control, and cloud connectivity — all in one compact device.
With its 5-inch, 1500-nit HDR touchscreen, Ninja TX GO offers a far superior monitoring experience than the camera’s built-in display. It features professional tools such as EL Zone™, waveform, vectorscope, focus peaking, and more, giving content creators complete control over framing, exposure, and color accuracy on-set.
Ninja TX GO records directly to CFexpress Type B or external USB-C SSD storage and supports Apple ProRes, ProRes RAW, Avid DNx, and H.265/H.264 formats, providing flexibility across post-production workflows. With RAW-capable HDMI inputs, it can record up to 6Kp30 RAW, delivering exceptional image quality from today’s leading mirrorless and DSLR cameras.
What truly sets Ninja TX GO — and Ninja TX — apart from previous Ninja models is integrated camera control — a free feature that will allow direct adjustment of exposure settings such as aperture, shutter speed, and ISO on supported cameras from Canon, Fujifilm, Nikon, Panasonic, Sony, Z CAM and other leading brands. This makes Ninja TX GO the complete on-camera companion for monitoring, recording, and control in one device.
Ninja TX GO includes built-in Wi-Fi for seamless camera-to-cloud operation, including 20GB of free ATOMOSphere cloud storage, enabling direct upload to ATOMOSphere, Frame.io, Dropbox, and other services, or live streaming via NDI 6/HX3.
For those who need even more advanced options, Ninja TX, launched earlier this year, adds SDI input/output, AirGlu wireless timecode, and expanded 8Kp30 RAW recording capabilities for cinematic cameras.
Both models run on the next-generation AtomOS platform, providing faster performance, over-the-air updates, and a more refined user experience. A robust locking cable system for HDMI and USB-C connections ensures reliability in the most demanding production environments.

What's New

Super-bright, 1500nit, 5-inch touchscreen display
All codecs preloaded - Apple ProRes/ProRes RAW, Avid DNx, H.265/H.264 and NDI 6 HX3 TX & RX
Capture up to 6Kp30 RAW to CFexpress Type B or USB-C media
2 x USB-C ports, plus one for power
Camera control and touch to foucs on supported cameras
Over-the-air firmware upgrades
Cooler, quieter operation
HDMI & Wi-Fi 6E input and output
Locking cable adaptors included (HDMI & USB-C)
Powered by USB-C, NP-F battery or AC adaptor
Tally light

Record up to 6Kp30 RAW over HDMI
Encode to Apple ProRes / ProRes RAW / Avid DNx / H.265 / H.264
Capture to CFexpress Type B or USB-C external storage
Super-bright, 1500-nit, 5-inch touchscreen display
Free camera control and touch-to-focus on supported camera models
Built-in Wi-Fi 6E for camera to cloud workflows
NDI 6 / HX3 TX/RX streaming capability
AtomOS Linux-based operating system with OTA updates
Secure locking HDMI / USB-C cable system
Powered by USB-C, NP-F battery or AC adaptor

Product Specifications

Dimensions (W x H x D mm): 151mm x 92mm x 36mm
Weight: 400gms
Mount points: 1 x anti-rotation 1/4-inch / 3/8-inch top and bottom

Environmental

Ambient operating temperature: Up to 40 degrees Celsius

Construction

Body: Aluminium with ABS plastic
Cooling: Actively controlled fan and heat sink

Power

Input voltage: 6.2V to 16.8V DC
Operating power: Up to 30W
Multi-function button: Power / lock screen
Continuous power: Via NP-F battery or USB-C PD Power
DC in connector: Via Battery Eliminator (optional)
DTAP: Up to 13W
USB PD IN: 45W capable, power supply required
USB PD OUT: Up to 13W

Display

Size: 5.2-inch
Resolution: 1920 x 1080
Backlight Type: Edge lit
Brightness (cdm2 / Nits): 1500
Aspect ratio: 16:9
Color Gamut: Rec.709
Calibration support: Calibrite Display Pro or Display Plus on PC/Mac with Atomos LANC cable

Color Pipeline

Gamma: Sony SLog / SLog2 / SLog3 / HLG, Canon C-Log / C-Log2 / C-Log3, ARRI Log CEI160 / LogCEI200 / LogCEI250 / LogCEI320, / LogCEI400 / LogCEI500 / LogCEI640 / LogCEI800 / LogCEI1000 / LogCEI1280 / LogCEI1600, Panasonic V-Log / HLG, JVC J-Log, Red RedLogFilm / Log3G10 / Log3G12, FujiFilm F-Log, PQ (HDR10), HLG, Nikon N-Log
Gamut: BT.2020, DCI P3, DCI-P3 D65, Rec709. Sony: S-Gamut / S-Gamut3 / S-Gamut3.cine / BT.2020 / Rec.709. Canon Cinema: DCI P3 / DCI P3plus / Rec.709. Panasonic: V Gamut. ARRI: Alexa Wide Gamut. JVC: LS300. RED: DragonColor / DragonColor2 / RedColor2 / RedColor3 / RedColor4 / RedWideGamut
3D LUT Display: .Cube format
3D LUT Down Stream: Loop out
3DLUT: 50/50 Yes
Monitoring Modes: Native / HLG / PQ / 3D LUT
HDR Output Conversion: Log / HDR to HLG / PQ

Video Input

HDMI: 1 x HDMI (2.0) up to 6Kp30
Locking port: Optional
Wi-Fi: Wi-Fi 6E
USB: 2 x USB-C 2.0/3.0
Bit Depth: 8/10-bit video
Video Chroma Subsampling: 4:2:2

Video Output

HDMI: 1 x HDMI (2.0) up to 6Kp30
Locking port: Optional
Wi-Fi: Wi-Fi 6E
USB: 2 x USB-C 2.0/3.0
Bit Depth: 8/10-bit video
Video Chroma Subsampling: 4:2:2

Metadata

HDMI: RAW - white balance, exposure index, shutter speed/angle, Iris F stop, ISO, gamma, gamut

Network

Wi-Fi: Wi-Fi 6E
USB: 2 x USB-C 2.0/3.0

Connectivity

Bluetooth: No
LANC: Yes

Audio In/Out

HDMI: 8-channel, 24-bit
Analogue Audio Line In: 3.5mm headphone jack, 2-channel input
Headphone Out: 3.5mm headphone jack, 2-channel

Timecode

Embedded: HDMI
Time of day: Yes
Reference / Genlock input: No
LTC: No
Wireless AirGlu RF Server and Client: No
Wireless AirGlu BT Server: No

Resolution & Frame Rates (Record, Monitor & Playback)

RAW: Up to 6Kp30
4K DCI: 23.98/24/25/29.9/30/50/59.94/60p
4K UHD: 23.98/24/25/29.9/30/50/59.94/60p
2K DCI 2048 x 1080: Yes
1080p: 23.98/24/25/29.9/30/50/59.94/60/100/120p
1080 PsF: Converted to P and looped out PsF
1080i: 50/59.94/60i
720p: 50/59.94/60p

Supported Media

CF Express: Atomos certified CF Express type B media
USB: Atomos certified USB 3.0 media
File System: ExFAT

Codecs

Apple ProRes RAW: ProRes RAW, ProRes RAW HQ
Apple ProRes: LT, 422, 422 HQ
Avid DNxHD: DNxHD 220x, 220, 145, 36
Avid DNxHR: LB, SQ, HQ, HQX
H.265: LQ, MQ, HQ, XQ in 8/10-bit, 4:2:2 and 4:2:0

Playback

Playlist: Yes - create customer playlists from full or sub-clips
Loop: Yes - with user-customizable in/out markers
Apple ProRes RAW: Yes - recorded clips
Apple ProRes: Yes - with linear PCM audio
Avid DNx: Yes - with linear PCM audio
H.265: Yes

Recording

Pre-roll: ProRes, DNxHD only
Timelapse: Yes
Simultaneous Proxy Record: Yes

On-screen Monitoring Tools

Waveform: 3 sizes – adjustable opacity & brightness
RGB parade: 3 sizes – adjustable opacity & brightness
Vectorscope: 2 sizes – adjustable opacity & brightness
1 x Zoom: Yes. 1:1 pixel mapping for 4K
2 x Zoom: Yes
Focus peaking: Colour selected / threshold setting / colour / mono / edges only
Atomos False Color: Yes, with scale
ARRI False Color: Yes
EL ZONE: Yes
Zebra: Yes, adjustable
Isolate color channel: Blue only
Cine Frame Guides: Presets for 2.4:1, 2.35:1, 1.9:1, 1.85:1, 4:3
Social Frame guides: Presets for 9:16, 1:1, 191:1, 4:5
Onion Skin: Yes
Safe areas: Action and graphic
Grid markers: 9 grid
Anamorphic desqueeze: 1.25x, 1.33x, 1.5x, 1.6x, 1.65x, 1.79x, 1.8x, 2x
Display Flip: Vertical only

Onboard Signal Processing

Pulldown removal: 24 / 25 / 30 pSF > 24 / 25 / 30p (2:2 pulldown), 60i > 24p (3:2 pulldown)
4K UHD downscale for HD: Loop out - 4K UHD to HD
DCI Crop: Loop out - 17:9 to 16:9 crop

Remote Control

HDMI: Auto HDMI trigger, supported protocols - Canon, Sony, Atomos
Serial 2.5mm Jack: Calibration via optional USB to serial cable
AirGlu BT: No
AirGlu RF: No

Camera to Cloud

ATOMOSphere: Direct progressive upload supported (20GB free storage)
Adobe Frame.io: Direct progressive upload supported (separate subscription service)
Dropbox: Direct progressive upload supported (separate subscription service)

What’s in the Box

Accessories included: Ninja TX GO monitor-recorder, USB-C locking cable adaptor, HDMI locking cable adaptor, 2x Wi-Fi antenna, 5x antenna tips (black, white, yellow, green, red), 2x antenna caps, USB-C locking cable (45cm), Quick Start Guide.
Box dimensions: (W x H x D mm) 190mm x 130mm x 75mm
Box weight: 665gms
