DAV Electronics BG1 2 Channel Mic Preamp
Dual Channel Microphone Pre-Amplifier
MPN: DAV-BG1 SKU: DAV-BG1
This Microphone Amplifier is ideal for location or studio recording.
Ask our team about our Price Match Pledge.
Get in touch
In stock
Usually Ships in 1-2 Days
This Microphone Amplifier is ideal for location or studio recording. Because of it's compact size it is easily transportable for location recording and is very discrete in the studio or control room. Its main qualities are that it is high quality at a low cost.
The features of this microphone amplifier consist of low noise and low distortion. It offers switched gain controls for high accuracy level setting, level indication, switchable high pass filters, input pads, split mode channel 1 shares its output with channel 2.
- Frequency Response: 10Hz - 150KHz ± 0.25dB
- Gain Range: 26dB - 59dB in 3dB steps. [pad in 0dB - 33dB]
- Distortion: Less than 0.01%. Typ, 0.001% 1KHz @ +20 dBu o/p
- High Pass Filters: 22Hz, 33Hz, 68Hz @ 12dB per octave.
- Noise: 25 microvolts [-110dB ref +20 dBu. Bandwidth 10Hz-18KHz input loaded 150 ohms, 32dB gain].
- Phase Reversal: CH 1 only
- Level Indication:
- Red LED +18dBu
- Green LED +15dBu
- Can be pre-set for your operating level
- 48v Phantom: Switchable
- Clipping Level: +29 dBu
- 26dB Pads: Ch 1 & Ch 2
- Dimensions: 60 x 115 x 295mm (HxWxD)
