Lilliput HT7S 7-Inch Ultra High Brightness Touch Control On-Camera Monitor
7 inch HDMI/SDI touch screen on-camera field monitor with HDR and 3D-LUT
MPN: HT7S SKU: HT7S
HT7S is a precision on-camera monitor with an amazing 2000 nits Ultra High Brightness and touch LCD screen which is capable of controlling video camera menu on set. Ideally suited for photographers and film makers, especially for outdoor video and film shooting.
Ask our team about our Price Match Pledge.
Get in touch
In stock
Usually Ships in 1-2 Days
- Model: HT7S
- Display: 7 inch, 1920×1200
- Input: 3G-SDI x 1; HDMI 2.0 x 1
- Output: 3G-SDI x 1; HDMI 2.0 x 1
- 2000nits
- HDR 3D-LUT
- Touch Screen
- Dual Batteries
- Camera Control
Display
- Panel: 7″ LCD
- Physical Resolution: 1920*1080
- Aspect Ratio: 16:10
- Brightness: 12000 nit
- Contrast: 1200: 1
- Viewing Angle: 160°/160°（H/V)
- Color Space: 100% BT.709
- HDR Supported: HLG; ST2084 300/1000/10000
Signal Input
- SDI: 1×3G SDI
- HDMI: 1×HDMI 2.0
Signal Loop Output
- SDI: 1×3G SDI
- HDMI: 1×HDMI 2.0
Supported Formats
- SDI: 1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60…
- HDMI: 2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60…
Audio In/Out (48kHz PCM AUDIO)
- HDMI: 8ch 24-bit
- Ear Jack: 3.5mm – 2ch 48kHz 24-bit
- Built-in Speakers: 1
Power
- Input Voltage DC 7-24V
- Power Consumption ≤16W (15V)
Environment
- Operating Temperature: 0℃~50℃
- Storage Temperature: -20℃~60℃
Other
- Dimension(LWD): 186mm × 128mm × 29mm
- Weight: 5.2kg
