Lynx Technik OCM 1800
18 Channel Fibre Optic CWDM Multiplexer (1270nm - 1610nm, LC connectors)
SKU: OCM-1800
The OCM 1800 is a compact 1RU CWDM passive 18-Channel optical multiplexer / demultiplexer designed to send or receive up to 18 individual signals over a single fiber link. The module does not use an internal upgrade port which improves signal strength compared to using daisy chained multiplexer/demultiplexer.
It is fully compatible with other LYNX Technik OCMs.
Ask our team about our Price Match Pledge.
Get in touch
In stock
Usually Ships in 1-2 Days
The OCM 1800 is a compact 1RU CWDM passive 18-Channel optical multiplexer / demultiplexer designed to send or receive up to 18 individual signals over a single fiber link. The module does not use an internal upgrade port which improves signal strength compared to using daisy chained multiplexer/demultiplexer.
It is fully compatible with other LYNX Technik OCMs.
The modules can be rack mounted without the need for additional component using the rack ears provided.
Ideally suited for use with the CWDM yellobrik fiber modules (all 18 wavelengths).
- Mux/DeMux up to 18 Channels over a Single Fiber
- 1270nm to 1610nm (ITU-T G.694.2)
- Passive Device (no power required)
- Combines with 9 or 4-Channel OCMs
- 1RU Self mounted
Video and Data Formats
- 12G-SDI
- 6G-SDI
- 3G-SDI
- 1.5G-SDI
- SD-SDI
- 10GbE
- 1GbE
Fiber Inputs
- 18x Simplex/Duplex Single-mode
- LC/PC Connection
Fiber Outputs
- 1x Simplex Single-mode
- LC/PC Connection
