Pultec EQM-1A

Mastering Version of EQP-1A Equalizer

MPN: PULTEC-EQM-1A SKU: PULTEC-EQM-1A

$4,329.17

Mastering version of the legendary Pultec EQP-1A with 0.5dB stepped gain controls.

Seen it cheaper?

Ask our team about our Price Match Pledge.

Get in touch

In stock

Special Order - Usually ships in 1-2 weeks

The Pultec EQM-1A mastering eq is a modern recreation of the legendary EQP-1A with added stepped controls for mastering applications providing you with the huge low end, silky smooth highs and warmth that make Pultec EQs so popular and sought-after.

The Pultec EQM-1A has been meticulously adapted from the EQP-1A, using only original-spec components to recreate the same stunning sound of the original vintage units. Adapted for mastering applications the EQM-1A features Progressive-taper Elma switch controls with a 0.5dB of boost and cut for precise settings and easy recall. As a result, the gain has been reduced to 10dB boost/cut instead of the original values

Low shelf boost: +10 dB in .5 dB steps @ 20, 30, 60, 100 Hz
Low shelf attenuate: -10 dB in .5 dB steps @ 20, 30, 60, 100 Hz
Mid/high peak boost: +10 dB in .5 dB steps@ 3, 4, 5, 8, 10, 12, 16 kHz
High shelf attenuate: -10 dB in .5 dB steps @5, 10, 20 kHz
Precision mastering-grade 21-position boost/cut rotary switches
Input impedance: ~600 ohms
Output impedance: ~50 ohms
Noise: 92 dB below +10 dBm
Distortion: ≤ 0.15% at +10 dBm into 600 ohms
Amplifier: Flat, 20 Hz to 20 kHz, +/- 0.5 dB
Tubes: 1 each - 12AU7, 12AX7, 6X4
