Roland V1200HDR Control Surface for V1200HD Video Switcher
Control Surface for the V-1200HD Multi-Format Video Switcher
MPN: RO-V1200HDR SKU: ROL-V-1200HDR
Control all the advanced functionality of your V-1200HD switcher with the optional V-1200HDR Control Surface. The V-1200HDR provides a professional physical control surface for the V-1200HD with dual LCD touchscreens for monitoring and control, a large T-bar for effects and transitions, customization and operation of the mix effects buses, HDMI video outs, and many buttons for source switching.
Ask our team about our Price Match Pledge.
Get in touch
In stock
Usually Ships in 1-2 Days
Adjust all the sophisticated functionality of your Roland V-1200HD switcher with the additional V-1200HDR Control Surface. The V-1200HDR delivers a premium physical control surface for the V-1200HD with dual LCD touchscreens for monitoring and control, a sizable T-bar for effects and transitions, customisation and operation of the mix effects buses, HDMI video outs, and a plethora of buttons for source switching.
A wide variety of cross-point switches permits a masterful simultaneous view of 16 sources. This is also interchangeable with either PGM/PST or flip/flop, depending on user preference, and a positioner joystick controls the PTZ parameters for up to seven connected remote cameras
Dual touch monitors display different GUIs on the left and right. Incoming video signals from the HDMI connectors on the rear panel can also be shown.
- Dual 7" LCD Touchscreen Displays
- Transition Control with T-Bar
- 16 Cross-Point Controls
- Display: 7 inch Graphic color LCD (touch screen) x 2
- Video input: HDMI (type A) x 2 * HDCP Supported
- Others:
- USB: Type A x 1 * USB Memory, USB: Type B x 1 * Use for future expansion
- LAN: RJ45 100Base-TX (Connect to V-1200HD)
- PHONES jack: Stereo 1/4-inch phone type x 1 (80 mW + 80 mW, 32 ohms)
- Internal mono speaker
- Power Supply: AC Adaptor, DC 9 V to 16 V (XLR-4-32 type) * Can not be used at the same time.
- Operation Temperature: +0 to +40 degrees Celsius +32 to +104 degrees Fahrenheit
- Dimensions:
- 520 (W) x 237 (D) x 111 (H) mm
- 20-1/2 (W) x 9-3/8 (D) x 4-3/8 (H) inches * Protruding parts not included.
- Weight: 4.3 kg / 9 lbs 8 oz
- V1200HDR
- AC Adaptor
- Power Cord
- Owner's Manual
