Small HD Cine 13 13" 4K HDR Monitor

4K HDR Reference-Grade Field Monitor

SKU: SHD-MON-CINE-13

$3,798.33

Cine 13 is SmallHD’s most agile, bright, and pixel-dense 4K production monitor yet. Low-profile in design, this portable field companion can be rigged in almost any situation. With brilliant daylight visibility and full 4K clarity, Cine 13 is built for those on-set creatives who require critical focusing capability for non-stop monitoring.

Seen it cheaper?

Ask our team about our Price Match Pledge.

Get in touch

In stock

Please Call for Lead Time

Small4K Video Processing Architcture

Inputs: 4x 12G-SDI , 1x HDMI 2.0
Outputs: 4x 12G-SDI, 1x HDMI 2.0*

Unibody Smart Chassis

Smartrail for battery and accessory mounting
2x 2-pin accessory power outputs
Lower mounting rail included for ultimate flexibility

PageOS 4 Software Platform

4K HDR waveform and scopes*
Dual & Quad-View*
Colour Pipe HDR color rendering
Monitor Calibration Wizard

Power

Hot-swappable dual inputs
1x 4-pin XLR input
1x Dual-GM/VM Battery Plate (sold separately)

13" 4K High-Bright Production Monitor
13.3in/34cm IPS LCD
1500+nits
10-bit (8+2)
Resolution: 3840x2160
Weight: 3.09kg / 6.8lbs

Environmental

Item Weight (oz): 108.8

Display

Diagonal Size: 13.3
Resolution: 3840x2160
Brightness: 1500nits
Contrast: 1300:1
Gamut: 100% REC.709
Color Depth: 10-bit (8+2)
Backlight Type: Edgelit
Display Size: 13"
Panel Resolution: 3840 x 2160
Brightness: 1500nits
Color Bit Depth: 10-bit (8+2)
Backlight Type: Edge-Lit
DCI-P3 Color: 100% REC.709

EVF

Height (in): 10.1 (w/out feet and handle) 12.4 (w/ feet and handle)
Width (in): 13.2 (w/out feet and handle) 13.2 (w/ feet and handle)
Depth (in): 2.3 (w/out feet and handle) 4.7 (w/ feet and handle)
Weight: 6.8lbs/3.09kg

Input Signal

12G-SDI Input Types: 4x 12G-SDI
HDMI Input Types: 1x HDMI 2.0 (4K60)

Output Signal

12G-SDI Output Types: 4x 12G-SDI
HDMI Output Types: Coming Soon
Audio Output Types: 1x 3.5mm 3-pin Stereo Headphone Jack (coming soon)

Data I/O

Connector Type: 1x SD Card Slot, 1x RJ45 Ethernet, 1x RJ45 GPI

Power

Input: 1x XLR 4-pin 12 - 34VDC IN (210W max, 12V-34V, 18A max)
Output: 2x 2pin (12V / 2A combined) 1x USB (2.4A) (Front) 1x USB (1.5A) (Front) 1x USB-C (5V / 1.5A)
Consumption: 36.7w (monitor only) 117.9w (w/max access. power draw)
Battery Plate Included: No
Battery Types: 1x Dual-GM/VM Batt.Plate (14/26V) (sold as accessory)

1x Cine 13 Monitor (MON-CINE-13)
1x 1300 Basic Acrylic Screen Protector (ACC-SP-1300-ACR)
1x 4K HDMI to 4K HDMI Cable (CBL-SGL-HDMI-4K-120)
1x 1/4-20 Cheese Stick for SmallHD 4K Monitors (ACC-MT-STICK-STANDARD)
1x Extra Thick Combination Cheese Stick for SmallHD 4K Monitors (3/8 and 1/4 20) (ACC-MT-STICK-COMBO-THICK)
1x SmallHD 4K Monitor Feet Set (ACC-MT-FEET-4K)
1x SmallHD 4K Monitor Handle (ACC-HANDLE-4K)
1x 4-pin XLR AC/DC Power Adapter (PWR-ADP-XLR-15V-6A)
1x 8GB SD Card (ACC-SD-CARD-8GB-C10)
1x SmallHD Cleaning Cloth (ACC-CLOTH-SMALLHD)
