Small HD Cine 5 Monitor
Field-ready, 5-inch monitor with 2000nits of brightness and joystick control
SKU: SHD-16-0526
Cine 5 is lightweight, compact, and offers 2000nits brightness for full visibility even in direct sunlight. Optional camera-control functionality (software license and cable sold separately) allows users to start, stop, record, and more from the convenience of their Cine 5. Experience all your favorite PageOS 5 tools, functions, and settings pages on this field-ready 5-inch monitor.
Ask our team about our Price Match Pledge.
Get in touch
In stock
Coming Soon
Cine 5 is lightweight, compact, and offers 2000nits brightness for full visibility even in direct sunlight. Optional camera-control functionality (software license and cable sold separately) allows users to start, stop, record, and more from the convenience of their Cine 5. Experience all your favorite PageOS 5 tools, functions, and settings pages on this field-ready 5-inch monitor.
1080p resolution ensures a clear look at your production, while 10-bit color processing offers excellent color accuracy. The added joystick and back button allow you to use this smart monitor in nearly all conditions, even on cold days when taking off your gloves is not an option.
Cine 5 is designed for high-end camera use – with bright imagery, optional Camera Control, and 2-pin locking power input – making it ideal for First ACs, Camera Operators, and DPs.
Camera Control For RED DSMC2 & RCP2
Transform your touchscreen into the central command hub of your camera. SmallHD’s proprietary software enables unfettered access to RED DSMC2, KOMODO®, and V-RAPTOR™ camera functions and project settings such as Start/Stop Record, FPS, Shutter Speed, ISO, Color Temperature/White Balance, Clip Playback, and more.
Individual Camera Control software licenses are sold separately.
Additional Camera Control compatibility coming soon.
- Field-ready, 5-inch monitor with 2000nits of brightness and joystick control
- Model: 16-0526
- Display: 5-inch Touchscreen, 1920x1080, 440 PPI
- Input: 1x 3G-SDI [IN], 1x HDMI 2.0 (4Kp30) [IN],
- Output: 1x 3G-SDI [IN/OUT], 1x HDMI 2.0 (4Kp30) [OUT], 1x 3.5mm Stereo Headphone Jack
- Power Input: 2-pin Locking Power Input (10-34V DC, 1.6A)
- Data I/O: 1x SD Card Slot, 1x Micro USB, 1x Locking USB
Environmental
- Mount Points: 6x 1/4-20 Mounting Points
- User Function Buttons: Side Joystick Side Back-Button
Display
- Panel Type: Touch-Screen
- Resolution: 1920 x 1080
- Aspect Ratio: 16:9
- Brightness: 2000nits
- Backlight Type: Edgelit
Input Signal
- 3G-SDI Input Types: 1x 3G-SDI
Output Signal
- HDMI Output Types: 1x HDMI 2.0 (4Kp30)
Connector Type
- SDI: 1x 3G-SDI (In), 1x 3G-SDI (In/Out)
- HDMI: 1x HDMI 2.0 (4Kp30) [In], 1x HDMI 2.0 (4Kp30) [Out]
- Audio: 1x 3.5mm Stereo Headphone Jack
Data I/O
- Storage Media: 1x SD Card Slot
- USB: 1x Micro USB 1x Locking USB
Power
- Input: 2-pin Locking Power Input (10-34V DC, 1.6A)
Software
- Pixel Zoom: Yes
- Focus Assist: Yes
- Peaking: Yes
- False Color: Customizable False Color Overlays
- Waveform: Customizable 4K Waveform w/Region of Interest Highlighting (Coming Soon)
- Custom LUTS: 17pt 3D-LUT on Output/Input 33pt 3D-LUT on Output/Input
Camera Control
- Camera Control Compatibility: Camera Control for RED® DSMC2™ Camera Control for RED® RCP2™ Cameras (KOMODO®, DSMC3™) *Additional camera control compatibility coming soon
Compare Chart
- Resolution: 1920 x 1080
- Color Depth: 10-Bit Color Intelligence Engine
- Brightness: 2000nits
- SDI (1080p60): 1x 3G-SDI Input 1x 3G-SDI (I/O)
- HDMI (4Kp30): 1x HDMI 2.0 Input 1x HDMI 2.0 Output
- Touchscreen: ✔️
- Joystick Control: Side Joystick
- Physical Buttons: Side Back-Button
- Power Input: 2-pin Locking Connector
- Locking USB Control Port: ✔️
- Ethernet Port: ❌
- Camera Control Compatibility*: REDⓇ
- Battery Support: Integrated Sony L-Series
- Touchscreen Lock: ✔️
- Built-in Teradek Bolt 6: ❌
- Cine 5
